Give the file a name and specify the directory if desired. To save a set of items, click on the VCDS logo found on the top left corner of the item selection window, and then select "Save selection to file": For instance, if you often log Vehicle Speed, Engine Speed, Intake Air Mass, and Ignition timing, then you can create a file to quickly load those selections again.
VCDS lets you save a list of Advanced Measuring Values, to be easily accessed later on. Use the data entry box on top to filter only the items containing the word you enter such as "time" shown here. For controllers using the UDS/ODX/ASAM protocol, the naming of each Location should coincide with factory identifiers for various data objects like IDEnnnnn. Check each value you would like to show and uncheck each that you would like to remove. The Advanced Measuring Values function has two screens, the main one shown above and the Item Selection Window shown below. For controllers using the UDS/ODX/ASAM protocol, the "Group UDS requests" checkbox can speed up sample rates. On modules using the UDS/ODX/ASAM protocol, the Measuring Blocks function is not available and you MUST use Advanced Measuring Values instead. On non-UDS modules these can be from as many as 12 different Measuring Block Groups, but this function is available only when a label file exists for the control module being accessed. This function expands on the Measuring Blocks function and lets you select up to 12 measuring values from a single control module using a selection dialog that shows the contents of the measuring values. There is a good chance that you can generate your own list (specifically for your controller) from this label file.Online Demo / Manual- Advanced Measuring Values Your best bet might be to open up the appropriate label file and read it. When you open up a controller, VCDS should tell you what label file it is using. The label file should be accurate enough that the blocks should be named. Do you have VCDS? Just open up the controller in question and scroll through the measuring blocks.
Not to mention which controller (engine, ABS, Instrument panel, automatic transmission, etc.).Įxactly what are you looking for? Most people are usually looking for engine measuring blocks, so they can log boost numbers and other engine performance data. Therefore a "master list" of measuring blocks would have hundreds of footnotes to clarify exactly which year and model car they apply to. Different model and year VWs have different controllers installed. The problem is that every different controller potentially has it's own measuring blocks.
